| Brand | Ubiquiti UniFi |
| Dimensions | Ø215 × 32.5 mm |
| Weight | 800 g |
| Ports / connectivity | 10 GbE RJ45 port |
| Power method | PoE++ |
| WiFi standard | WiFi 7 |
| Spatial streams | 8 |
| Coverage area | 160 m² |
| Maximum client count | 500+ |
| MIMO | 6 GHz: 2×2, 5 GHz: 4×4, 2.4 GHz: 2×2 (DL/UL MU-MIMO) |
| Max data rate | 6 GHz: 5.8 Gbps, 5 GHz: 8.6 Gbps, 2.4 GHz: 688 Mbps |
| Antenna gain | 6 GHz: 6 dBi; 5 GHz: 6 dBi; 2.4 GHz: 4 dBi |
| Max TX power | 6 GHz: 24 dBm; 5 GHz: 29 dBm; 2.4 GHz: 23 dBm |
| Max BSSIDs | 8 per radio |
| Wireless features | Meshing, band steering, 802.11v/r/k, zero-wait DFS, RRM, PPSK, RadSec, VLAN assignment |
| Captive portal | Branding page, vouchers, payment-based, external server, passwords |
| Max power consumption | 29 W |
| Supported voltage range | 42.5–57 V DC |
| Enclosure material | UV-stabilised polycarbonate, aluminium alloy |
| Mount material | Stainless steel (SUS304), galvanised steel (SGCC) |
| LED indicators | System: White/Blue |
| Operating frequency | US/CA: 2400–2472, 5150–5850, 5925–7125 MHz; Worldwide: 2400–2483.5, 5150–5725, 5925–7125 MHz |
| Channel bandwidth | HT/VHT/HE/EHT 20–320 MHz |
| Operating temperature | -30 to 40 °C |
| Operating humidity | 5–95% noncondensing |
| NDAA compliant | Yes |
| Certifications | CE, FCC, IC, Anatel: 05123-25-08356 |
| Software requirements | UniFi Network 9.0.114+ (White), 9.1.120+ (Black) |
Ubiquiti U7 Pro XGS WiFi 7 Access Point Dual-Band
$679.00 incl. GST
The Ubiquiti UniFi WiFi 7 access point delivers exceptional performance with advanced 8-stream connectivity, 6 GHz capability, and a powerful 10 GbE uplink designed for high-density environments. Its broad 160 m² coverage and support for more than 500 client devices make it ideal for modern homes, offices, and enterprise spaces requiring low-latency, wired-grade wireless performance. With a dedicated spectral scanning radio for interference detection, the U7 Pro XGS optimises channel selection and improves network stability, ensuring more consistent speeds and reduced congestion across mission-critical deployments daily.
This model combines a refined thermal architecture with a sleek, ceiling-mountable enclosure crafted from UV-stabilised polycarbonate and aluminium alloy for durability in demanding environments. PoE++ power input simplifies installation while supporting high-throughput WiFi 7 features such as MU-MIMO, wide channel bandwidths up to 320 MHz, and multi-band steering intelligence. Integrating seamlessly with UniFi Network 9, it provides enhanced analytics, improved automation, and smarter optimisation tools for long-term scalability. Available in both white and black finishes, the U7 Pro XGS complements any interior while offering high-performance connectivity, real-time spectral analysis, zero-wait DFS, and secure access control features including PPSK and RadSec support. This access point is engineered to modernise wireless networks with superior throughput and extraordinary user experience everywhere.
Key features:
- WiFi 7 technology delivers ultra-fast speeds for high-density environments effortlessly.
- 8-stream architecture boosts capacity for smooth performance across many devices.
- Dedicated spectral scanning improves channel decisions and reduces interference.
- 10 GbE uplink unlocks full WiFi 7 throughput for next-generation deployments.
- PoE++ support simplifies installation and provides stable, high-performance operation.
- Advanced roaming and band-steering features enhance mobility across sites.
- Real-time spectral analysis empowers administrators with deeper insights.
- UniFi Network integration enables efficient management and long-term scalability.
