UniFi Pro 24 PoE switch (24-port / 400W)

$1,743.00 incl. GST

The UniFi Pro 24 PoE switch is a high-performance, enterprise-grade switch designed to power and connect multiple devices across professional networks. Equipped with 24 Gigabit Ethernet ports, including 16 PoE+ and 8 PoE++ ports, it delivers a total PoE budget of 400W, making it ideal for powering UniFi access points, cameras, and VoIP phones.

Engineered for speed and resilience, the UniFi Pro 24 PoE switch features 44 Gbps non-blocking throughput, a switching capacity of 88 Gbps, and a forwarding rate of 65 Mpps. With Layer 3 capabilities, advanced VLAN support, and redundancy options via DC power backup, this switch ensures reliable connectivity for demanding environments. Housed in a durable SGCC steel enclosure with a 1U rack-mount form factor and a 1.3″ touchscreen display, it combines robust design with intuitive management through UniFi Network software.

Key features:

  • 24 Gigabit Ethernet ports with 16 PoE+ and 8 PoE++ support.
  • 400W total PoE budget for powering high-demand devices.
  • Layer 3 functionality with DHCP, inter-VLAN routing, and static routing.
  • 44 Gbps non-blocking throughput and 88 Gbps switching capacity.
  • Durable SGCC steel enclosure with 1U rack-mount design.
  • 1.3″ touchscreen display for simplified monitoring and management.
  • Supports up to 1,000 VLANs and advanced IGMP configurations.
  • Comprehensive access control with ACLs, port security, and device isolation.
  • Compatible with UniFi Network application version 5.10.5 and later.
  • Backed by a 5-year limited warranty for long-term reliability.

Networking, Switches, Unifi, Unifi, Unifi, Network – Switches
Networking, Switches, Unifi, Unifi, Unifi, Network – Switches
Networking, Switches, Unifi, Unifi, Unifi, Network – SwitchesNetworking, Switches, Unifi, Unifi, Unifi, Network – Switches

Categories: , , , , , Tag:
Brand UniFi
Ports 24 × 1 GbE RJ45 (16 PoE+, 8 PoE++), 2 × 10G SFP+
PoE availability 400W total (PoE+, PoE++)
Max PoE per port 15.4W (PoE), 30W (PoE+), 64W (PoE++)
Switching capacity 88 Gbps
Non-blocking throughput 44 Gbps
Forwarding rate 65 Mpps
VLAN support Up to 1,000 VLANs
MAC address table 16,000 entries
Layer 3 features DHCP server, DHCP relay, inter-VLAN routing, static routing
Layer 2 features LACP, STP/RSTP, QoS (DSCP), IGMP snooping, 802.1X, ACLs, jumbo frames, LLDP-MED, voice VLAN
Power supply AC/DC internal, 450W
Power input 100–240V AC, 50/60 Hz, USP RPS DC backup input
Max power consumption 50W (excluding PoE), 450W (including PoE)
Heat dissipation 170.6 BTU/hr (excluding PoE)
Enclosure SGCC steel
Mounting Rack depth 400–1200 mm, SGCC steel brackets
Display 1.3″ touchscreen LCM
Operating temperature -5 to 40 °C
Operating humidity 10–90% noncondensing
Certifications CE, FCC, IC, Anatel, NDAA compliant
Management UniFi Network application version 5.10.5 and later
Dimensions 442 × 285 × 44 mm
Weight 4.3 kg (without brackets), 4.4 kg (with brackets)
Warranty 5 years limited warranty
Form factor Rack mount (1U)
