Dimensions | Ø197 x 35 mm (Ø7.8 x 1.4″) |
Weight | Without mount: 580 g (1.3 lb) With mount: 720 g (1.6 lb) |
Enclosure material |
Polycarbonate |
Mount material | Stainless steel (SUS304) |
Weatherproofing | IP54 |
Networking interface | (1) GbE RJ45 port |
Management interface | Ethernet Bluetooth |
Networking interface | (1) GbE RJ45 port |
Power supply | UniFi PoE switch PoE adapter (Not included) |
Power method | PoE |
Supported voltage range | 44—57V DC |
Max. power consumption | 13W |
Max. TX power 2.4 GHz 5 GHz 6 GHz |
22 dBm 26 dBm – |
MIMO 2.4 GHz 5 GHz 6 GHz |
2 x 2 (UL MU-MIMO) 4 x 4 (DL/UL MU-MIMO) –/span> |
Throughput rate 2.4 GHz 5 GHz 6 GHz |
573.5 Mbps (BW40) 4.8 Gbps (BW160) – |
WiFi standards | 802.11a/b/g/n/ac/ax (WiFi 6) |
Wireless security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) |
WiFi standards | 802.11a/b/g/n/ac/ax (WiFi 6) |
BSSID | 8 per radio |
VLAN | 802.1Q |
Advanced QoS | Per-user rate limiting |
Guest traffic isolation | Supported |
Concurrent clients | 350+ |
