30M LMR400 with Ntype Male Connector – Antenna Cable
$249.70 incl. GST
The 30-meter LMR-400 antenna cable with N-type male connectors is a high-performance, low-loss coaxial cable designed for RF applications, including antenna feeder runs and jumper assemblies. Manufactured by Times Microwave Systems, the LMR-400 cable offers superior flexibility and low attenuation, making it a suitable replacement for traditional RG-8/9913 cables.
Cable assembly features:
- Black polyethylene outdoor flooded weather-proof UV resistant 10.3mm jacket.
- Double shielded with copper braid coverage of over 93% and 100% Aluminium tape coverage.
- Extra wide bandwidth Gas-Injected Foam Polyethylene 7.2mm insulator.
- Copper over Aluminium (Al-Cu) Solid Centre Conductor 2.74mm.
- High quality RF connectors with soldered pin, crimped shield and adhesive heat shrink insulation.
Clearance Items
| Cable Type | LMR-400 |
| Length | 30 meters (approximately 98.4 feet) |
| Connectors | N-type male on both ends |
| Impedance | 50 ohms |
| Outer Diameter | 10.29 mm (0.405 inches) |
| Minimum Bend Radius | 25.4 mm (1 inch) |
| Operating Temperature Range | -40°C to +85°C (-40°F to +185°F) |
| Maximum Frequency | 6 GHz |
| Jacket Material | UV-resistant polyethylene (PE) |
| Weight | 0.1012 kg/m (0.068 lb/ft) |
